Construction Layout & Site Stakeout
Turn the issued drawings into usable references on site. Layout and stakeout for buildings, roads, curbs, sidewalks and services.
Understand the service
What is construction layout?
Construction layout establishes the points, lines and elevations the contractor needs to position the proposed work. Grad Surveying supports residential builds and infrastructure work, including water mains, storm and sanitary services, sidewalks, curbs and roadways. We coordinate the survey brief with the current drawing revision and the stage that is ready for construction.
Is this right for you?
When might you need it?
Installing infrastructure
Identify the roadway, curb or service elements needing survey support.
Planning site visits
Align layout with excavation, access and the contractor's program.
Define the assignment
What can the scope include?
We confirm the survey information and deliverables your assignment needs. The following items guide that discussion.
Design review
Confirm the issued drawing revision and the requested layout elements.
Field references
Agree the points, lines, levels or control needed by the site team.
Survey layout
Carry out the field positioning within the assigned scope.
Follow-on surveying
Identify later layout, checking and as-built requirements separately.
Your deliverables: The agreed field references and associated documentation. Additional visits, replacement of disturbed markers and final as-built surveys should be identified in the quote.
From inquiry to handoff
Your survey, step by step
Send the drawings
Identify the elements and levels to be laid out.
Coordinate readiness
Agree access, site contact and when the area will be ready.
Set out the work
Complete the specified layout against the agreed design.
Handover and follow up
Explain the references and discuss any further visits.
Make the first conversation count
What to have ready
- Site address and contact
- Current construction drawings
- Required layout elements
- Site-readiness date and programme
Missing a document? Start with the address and a short description. We can discuss what else is needed. Please do not send payment or identification documents.
Start Your InquiryBefore you get started
Frequently asked questions
Is layout the same as an as-built survey?
No. Layout helps position proposed construction. An as-built survey records the constructed condition.
What if the design changes?
Send the new revision before further work. Changes may affect existing field references and the remaining scope.
Do you support utility and roadway work?
Yes. Those applications are part of our construction-layout services. Send the project drawings and requirements for review.
Ready for the next step?
Let's discuss your surveying needs.
Share your property location and project requirements. We will confirm the surveying scope, scheduling and site-visit arrangements as part of your quote.
